Bow Spring Centraliser
Flow-Activated
The Flow Activated Bow Spring Centraliser is used to assist in positioning a Coiled Tubing BHA within large bore completions after passing through restrictions above
The Flow Activated Bow Spring Centraliser is used to assist in positioning a Coiled Tubing BHA within large bore completions after passing through restrictions above
Back pressure created within a piston chamber on the central carrier mandrel will expand the arms to the required effective OD. Decreasing the pump rate / volume will allow the arms to collapse back to their original running diameter. The effective OD of the Bow Spring can be adjusted by rotating the adjustable sleeve and lock nut.
High deflection range from minimum to maximum OD
Optional effective OD’s to suit client needs
Interchangeable flo-nozzles
Simple, robust design ensuring ease of operation for the user
Hexagonal flats for safe make-up & break-out
Connection options to suit customer requirements
