TEC Cablehead
Speciality tools
The Cablehead provides a primary well control barrier and a means of running logging tools or perforating guns on Coiled Tubing.
The Cablehead provides a primary well control barrier and a means of running logging tools or perforating guns on Coiled Tubing.
The tool features; double flapper check valves, a cable anchor and release mechanism, a flow activated disconnect as well as the means to pass an electrical signal to the tools below. The disconnect mechanism and lower electrical section can be replaced with a conventional flow& Tension Disconnect, whilst the cable remains anchored, allowing conventional CT work to be carried out with the same string.
Single piece cartridge type Double Flapper Check Valve safety system
High tensile and compressive strength rating
10,000 psi Safe Working Pressure
Flow and Tension release mechanism
Offset bores to maximise flapper ID’s for conventional operations
Disconnect Sub fitted with GS type internal fish neck profile
Hexagonal flats for safe make-up & break-out
Corrosion resistant materials
