Retrievable inflatable bridge plug
RIBP incorporates a valving system in conjunction with a packer element, which provides bi-directional sealing and anchoring
RIBP incorporates a valving system in conjunction with a packer element, which provides bi-directional sealing and anchoring
The RIBP has an innovative design with an equalization mechanism allowing the operator to equalize pressure across the packer, before activating the deflation mechanism. There are several methods of deployment such as drill pipe, coiled tubing and capillary tube.
Achimgas needed to replace a malfunctioning wellhead on a producing well in the Urengoi field, which had a bottomhole pressure of 450 bar and a temperature of 98 °C.
Our team provided a Retrievable Inflatable Bridge Plug (RIBP) equipped with SYMOIL’s proprietary valving system and a high-performance inflatable sealing element. It was deployed via coiled tubing to ensure accurate placement within the wellbore, even in the challenging environment of the Urengoi formation.
The RIBP was successfully run in hole and set just below the wellhead in a single coiled tubing run, eliminating the need for additional intervention equipment
Inflation was performed from the surface, establishing a robust pressure barrier capable of withstanding 450 bar and 98 °C, enabling the safe removal of the damaged wellhead
Following the wellhead replacement, the plug was safely retrieved via coiled tubing
